TEKTRONIX P6139A PASSIVE PROBE 500MHz 10MΩ X10 WITH 1.3M CABLE AE1W98

TEKTRONIX P6139A PASSIVE PROBE 500MHz 10MΩ X10 WITH 1.3M CABLE AE1W98

£80.00
£80.00
Sale Sold out
Taxes included.



TEKTRONIX P6139A OSCILLOSCOPE PROBE 500MHz

Manufactured by Tektronix as their part number P6139A, this is an industry standard BNC interface passive probe, commonly used with the TDS500, TDS600 TDS3000 and other similar instruments.

The P6139A is a compact high impedance passive probe, it has a 1.3-meter cable and is fully compatible with the Tektronix family of compact size (3.5 mm) probe accessories.

 ≥500 MHz Bandwidth
300V peak (max)
8 pF Input Capacitance
10 MΩ Input Resistance
X10
1.3m long cable

Not new, but it has had very little use and is sold in perfect working and cosmetic condition.

We have several of these in identical condition, the only difference is the probe color identification markings, if you want a particular color (blue, green, white) advise and we will supply if possible.
