APEM IP67 RATED WATERPROOF PUSH BUTTON SWITCH WITH GREEN LED BEST QUALITY fd5h7

APEM IP67 RATED WATERPROOF PUSH BUTTON SWITCH WITH GREEN LED BEST QUALITY fd5h7

£12.50
£12.50
Sale Sold out
Taxes included.


PREMIUM QUALITY PANEL ILLUMINATED PUSH SWITCH


Manufactured by Apem as their part number IPR3SAD2L0G, These are a very high quality panel mount push switch, sealed waterproof to IP67 standard.

 With single pole normally open (so push to make the circuit) momentary (not latching) gold plated contacts rated at 500mA.

Push button is black and about 12mm in diameter and has a very positive switch feel in activation.

There is a green LED manufactured flush into the center of the button, this has its own connections (requires 2V) and as such can be on all the time to show where the switch is in the dark, or be wired into the circuit to light when the switch is pressed.

Panel hole required is 12.9mm for fixing (fixing nut and neoprene washer included)  and the behind panel depth is 17.5mm including contacts.

Premium quality switch, the 100 off price for these from distribution is £13.80 each !
